500kW 1MWh containerized energy storage system
Engineered for commercial and industrial facilities, the ENERUVO 500kW / 1028kWh Containerized All-in-One ESS integrates advanced PCS, EMS, LFP batteries, intelligent thermal management, and fire safety systems into a standard IP54 container for seamless on/off-grid operation.
500kW 1MWh containerized energy storage system
The ENERUVO 500kW / 1MWh Containerized All-in-One Hybrid Energy Storage System is a highly integrated, turnkey power solution designed for commercial and industrial (C&I) applications. Combining advanced lithium iron phosphate (LFP) battery technology, high-performance PCS, EMS, temperature control, and fire safety systems into a single robust IP54 container, it delivers reliable backup power, peak shaving, and microgrid capabilities 500kW 1MWh containerized energy storage system
| Parameter | ENERUVO ESS 335kW / 1028kWh | ENERUVO ESS 500kW / 1028kWh |
| AC Output Power | 335kW | 500kW |
| AC Rated Current | 484A | 722A |
| On/off-grid Switch | <20ms | <20ms |
| Pack Capacity | 16.077kWh/1P16S | 16.077kWh/1P16S |
| Cell Type | LFP 314Ah | LFP 314Ah |
| Charge/Discharge Rate | 0.5C | 0.5C |
| Total Capacity | 1028kWh | 1028kWh |
| Max. PV Input Power | 960kW | 960kW |
| AC Maximum Power | 368kW | 550kW |
| Voltage Range | 360VAC~440VAC | 360VAC~440VAC |
| Frequency Range | 45~55Hz / 55~65Hz | 45~55Hz / 55~65Hz |
| IP Grade | Container | IP54 |
| Cooling Concept | Smart air cooling | Smart air cooling |
| Weight | <17t | <17t |
| Dimensions (W*D*H) | 6058*2438*2896mm | 6058*2438*2896mm |
